Help ! from base64 to file

Hi all,
i got a base64 image that i need to write on disk

i can correctly get in a webhook the base64 data

the data is correct

But i don’t understand how to use move binary data to get a binary .

Is this the right way ?
I certainly don’t understand something,

thanks for help


Instead of sending the image to the webhook as base64, it should be much simple to send the image as binary when making the HTTP request to the Webhook. That way, n8n would do the transformation for you, meaning the Function node does have to be used.

{
  "nodes": [
    {
      "parameters": {},
      "name": "Start",
      "type": "n8n-nodes-base.start",
      "typeVersion": 1,
      "position": [
        250,
        300
      ]
    },
    {
      "parameters": {
        "values": {
          "string": [
            {
              "name": "logo",
              "value": "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"
            }
          ]
        },
        "options": {}
      },
      "name": "Set",
      "type": "n8n-nodes-base.set",
      "typeVersion": 1,
      "position": [
        520,
        300
      ]
    },
    {
      "parameters": {
        "functionCode": "return [\n  {\n    json: {},\n    binary: {\n        data: {\n\t\t\t\tdata: items[0].json.logo,\n\t\t\t\tmimeType: 'image/png', // Optional but should be set if possible (optional)\n\t\t\t\tfileExtension: 'png', // Optional but should be set if possible (optional)\n\t\t\t\tfileName: 'logo.png', // Optional but should be set if possible (optional)\n\t\t\t}    }\n  }\n]"
      },
      "name": "Function",
      "type": "n8n-nodes-base.function",
      "typeVersion": 1,
      "position": [
        770,
        300
      ]
    },
    {
      "parameters": {
        "fileName": "image.png"
      },
      "name": "Write Binary File",
      "type": "n8n-nodes-base.writeBinaryFile",
      "typeVersion": 1,
      "position": [
        990,
        300
      ]
    }
  ],
  "connections": {
    "Start": {
      "main": [
        [
          {
            "node": "Set",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Set": {
      "main": [
        [
          {
            "node": "Function",
            "type": "main",
            "index": 0
          }
        ]
      ]
    },
    "Function": {
      "main": [
        [
          {
            "node": "Write Binary File",
            "type": "main",
            "index": 0
          }
        ]
      ]
    }
  }
}

hi @RicardoE105,
i understand that is a turnaround, i can send the raw format but when when binary data is set on, i got no response from the webhook.
I will open a new post
thanks
