N8n successfully instrumented with OpenTelemetry

Sharing this in the hope that it’s useful to anyone else self-hosting n8n who has been unhappy with the level of granularity present in logs. After some work, I’ve managed to get workflows and nodes to be fully instrumented with OpenTelemetry including workflow subflow nesting, parenting SQL queries to the nodes that caused them, and recording the JSON output of nodes. Here’s a screenshot:

A few details:

  1. We’re self-hosting via Docker. If you’re not self-hosting this is not possible.
  2. We’re using Honeycomb for trace analysis.

I’ll paste my code here in case it’s useful to anyone in the future. To the n8n team, I hope this should show how simple it would be to massively massively improve your observability support.

To use this, you’ll need to write your own Dockerfile which wraps the base n8n Dockerfile.

Dockerfile

FROM n8nio/n8n:latest

USER root

# Install required packages
RUN echo "Installing required packages..." && \
    apk add --no-cache \
    curl \
    gettext \
    coreutils \
    openssl \
    ca-certificates \
    musl-dev && \
    echo "Curl installed successfully: $(curl --version | head -n 1)" && \
    echo "Envsubst installed successfully: $(envsubst --version | head -n 1)"

# Switch to n8n's installation directory
WORKDIR /usr/local/lib/node_modules/n8n

# Install Node.js OpenTelemetry dependencies locally to n8n
RUN npm install \
    @opentelemetry/api \
    @opentelemetry/sdk-node \
    @opentelemetry/auto-instrumentations-node \
    @opentelemetry/exporter-trace-otlp-http \
    @opentelemetry/exporter-logs-otlp-http \
    @opentelemetry/resources \
    @opentelemetry/semantic-conventions \
    @opentelemetry/instrumentation \
    @opentelemetry/instrumentation-winston \
    @opentelemetry/winston-transport \
    winston \
    flat

# Copy instrumentation files to n8n directory
COPY tracing.js n8n-otel-instrumentation.js ./ # <- If you use different file names, change these
RUN chown node:node ./*.js

# Copy entrypoint script
COPY docker-entrypoint.sh /docker-entrypoint.sh
RUN echo "Setting entrypoint permissions..." && \
    chmod +x /docker-entrypoint.sh && \
    chown node:node /docker-entrypoint.sh && \
    echo "Entrypoint script contents:" && \
    cat /docker-entrypoint.sh

USER node

ENTRYPOINT ["tini", "--", "/docker-entrypoint.sh"]

n8n-otel-instrumentation.js

const { trace, context, SpanStatusCode, SpanKind } = require('@opentelemetry/api');
const flat = require('flat');
const tracer = trace.getTracer('n8n-instrumentation', '1.0.0');

function setupN8nOpenTelemetry() {
  try {
    const { WorkflowExecute } = require('n8n-core');

    /**
     * Patch the workflow execution to wrap the entire run in a workflow-level span.
     *
     * - Span name: "n8n.workflow.execute"
     * - Attributes prefixed with "n8n." to follow semantic conventions.
     */
    const originalProcessRun = WorkflowExecute.prototype.processRunExecutionData;
    /** @param {import('n8n-workflow').Workflow} workflow */
    WorkflowExecute.prototype.processRunExecutionData = function (workflow) {
      const wfData = workflow || {};
      const workflowId = wfData?.id ?? ""
      const workflowName = wfData?.name ?? ""

      const workflowAttributes = {
        'n8n.workflow.id': workflowId,
        'n8n.workflow.name': workflowName,
        ...flat(wfData?.settings ?? {}, { delimiter: '.', transformKey: (key) => `n8n.workflow.settings.${key}` }),
      };

      const span = tracer.startSpan('n8n.workflow.execute', {
        attributes: workflowAttributes,
        kind: SpanKind.INTERNAL
      });

      // Set the span as active
      const activeContext = trace.setSpan(context.active(), span);
      return context.with(activeContext, () => {
        const cancelable = originalProcessRun.apply(this, arguments);

        cancelable.then(
          (result) => {
            if (result?.data?.resultData?.error) {
              const err = result.data.resultData.error;
              span.recordException(err);
              span.setStatus({
                code: SpanStatusCode.ERROR,
                message: String(err.message || err),
              });
            }
          },
          (error) => {
            span.recordException(error);
            span.setStatus({
              code: SpanStatusCode.ERROR,
              message: String(error.message || error),
            });
          }
        ).finally(() => {
          span.end();
        });

        return cancelable;
      });
    };

    /**
     * Patch the node execution to wrap each node's run in a child span.
     *
     * - Span name: "n8n.node.execute"
     * - Captures node-specific details as attributes.
     */
    const originalRunNode = WorkflowExecute.prototype.runNode;
    /**
     * @param {import('n8n-workflow').Workflow} workflow
     * @param {import('n8n-workflow').IExecuteData} executionData
     * @param {import('n8n-workflow').IRunExecutionData} runExecutionData
     * @param {number} runIndex
     * @param {import('n8n-workflow').IWorkflowExecuteAdditionalData} additionalData
     * @param {import('n8n-workflow').WorkflowExecuteMode} mode
     * @param {AbortSignal} [abortSignal]
     * @returns {Promise<import('n8n-workflow').IRunNodeResponse>}
     */
    WorkflowExecute.prototype.runNode = async function (
      workflow,
      executionData,
      runExecutionData,
      runIndex,
      additionalData,
      mode,
      abortSignal
    ) {
      // Safeguard against undefined this context
      if (!this) {
        console.warn('WorkflowExecute context is undefined');
        return originalRunNode.apply(this, arguments);
      }

      const executionId = additionalData?.executionId ?? 'unknown';
      const userId = additionalData?.userId ?? 'unknown';

      const node = executionData?.node ?? 'unknown';
      let credInfo = 'none';
      if (node?.credentials && typeof node.credentials === 'object') {
        const credTypes = Object.keys(node.credentials);
        if (credTypes.length) {
          credInfo = credTypes
            .map((type) => {
              const cred = node.credentials?.[type];
              return cred && typeof cred === 'object'
                ? (cred.name ?? `${type} (id:${cred?.id ?? 'unknown'})`)
                : type;
            })
            .join(', ');
        }
      }

      const nodeAttributes = {
        'n8n.workflow.id': workflow?.id ?? 'unknown',
        'n8n.execution.id': executionId,
      };

      const flattenedNode = flat(node ?? {}, { delimiter: '.' });
      for (const [key, value] of Object.entries(flattenedNode)) {
        nodeAttributes[`n8n.node.${key}`] = value;
      }

      return tracer.startActiveSpan(
        `n8n.node.execute`,
        { attributes: nodeAttributes, kind: SpanKind.INTERNAL },
        async (nodeSpan) => {
          try {
            const result = await originalRunNode.apply(this, [workflow, executionData, runExecutionData, runIndex, additionalData, mode, abortSignal]);
            try {
              const outputData = result?.data?.[runIndex];
              const finalJson = outputData?.map((item) => item.json);
              nodeSpan.setAttribute('n8n.node.output_json', JSON.stringify(finalJson));
            } catch (error) {
              console.warn('Failed to set node output attributes: ', error);
            }
            return result;
          } catch (error) {
            nodeSpan.recordException(error);
            nodeSpan.setStatus({
              code: SpanStatusCode.ERROR,
              message: String(error.message || error),
            });
            nodeSpan.setAttribute('n8n.node.status', 'error');
            throw error;
          } finally {
            nodeSpan.end();
          }
        }
      );
    };

  } catch (e) {
    console.error("Failed to set up n8n OpenTelemetry instrumentation:", e);
  }
}

module.exports = setupN8nOpenTelemetry;

tracing.js

"use strict";

// Enable proper async context propagation globally.
const { AsyncHooksContextManager } = require("@opentelemetry/context-async-hooks");
const { context } = require("@opentelemetry/api");
const contextManager = new AsyncHooksContextManager();
context.setGlobalContextManager(contextManager.enable());

const opentelemetry = require("@opentelemetry/sdk-node");
const { OTLPTraceExporter } = require("@opentelemetry/exporter-trace-otlp-http");
const { OTLPLogExporter } = require("@opentelemetry/exporter-logs-otlp-http");
const { getNodeAutoInstrumentations } = require("@opentelemetry/auto-instrumentations-node");
const { registerInstrumentations } = require("@opentelemetry/instrumentation");
const { Resource } = require("@opentelemetry/resources");
const { SemanticResourceAttributes } = require("@opentelemetry/semantic-conventions");
const setupN8nOpenTelemetry = require("./n8n-otel-instrumentation");
const winston = require("winston");

const logger = winston.createLogger({
  level: "info",
  format: winston.format.json(),
  transports: [new winston.transports.Console()],
});

const autoInstrumentations = getNodeAutoInstrumentations({
  "@opentelemetry/instrumentation-dns": { enabled: false },
  "@opentelemetry/instrumentation-net": { enabled: false },
  "@opentelemetry/instrumentation-tls": { enabled: false },
  "@opentelemetry/instrumentation-fs": { enabled: false },
  "@opentelemetry/instrumentation-pg": {
    enhancedDatabaseReporting: true,
  }
});

registerInstrumentations({
  instrumentations: [autoInstrumentations],
});

setupN8nOpenTelemetry();

const sdk = new opentelemetry.NodeSDK({
  logRecordProcessors: [
    new opentelemetry.logs.SimpleLogRecordProcessor(new OTLPLogExporter()),
  ],
  resource: new Resource({
    [SemanticResourceAttributes.SERVICE_NAME]: process.env.OTEL_SERVICE_NAME || "n8n",
  }),
  traceExporter: new OTLPTraceExporter({
    headers: {
      "x-honeycomb-team": process.env.HONEYCOMB_API_KEY,
    },
  }),
});

process.on("uncaughtException", async (err) => {
  logger.error("Uncaught Exception", { error: err });
  const span = opentelemetry.trace.getActiveSpan();
  if (span) {
    span.recordException(err);
    span.setStatus({ code: 2, message: err.message });
  }
  try {
    await sdk.forceFlush();
  } catch (flushErr) {
    logger.error("Error flushing telemetry data", { error: flushErr });
  }
  process.exit(1);
});

process.on("unhandledRejection", (reason, promise) => {
  logger.error("Unhandled Promise Rejection", { error: reason });
});

sdk.start();

docker-entrypoint.sh

#!/bin/sh

# Set up OpenTelemetry environment variables for Honeycomb
export OTEL_SERVICE_NAME="${OTEL_SERVICE_NAME:-n8n}"
export OTEL_EXPORTER_OTLP_PROTOCOL="http/protobuf"
export OTEL_EXPORTER_OTLP_ENDPOINT="https://api.honeycomb.io"
export OTEL_EXPORTER_OTLP_HEADERS="x-honeycomb-team=${HONEYCOMB_API_KEY}"
export OTEL_EXPORTER_OTLP_TRACES_HEADERS="x-honeycomb-team=${HONEYCOMB_API_KEY}"
export OTEL_LOG_LEVEL="info"

# Start n8n with OpenTelemetry instrumentation
echo "Starting n8n with OpenTelemetry instrumentation and Honeycomb export..."
exec node --require /usr/local/lib/node_modules/n8n/tracing.js /usr/local/bin/n8n "$@"
7 Likes

This is amazing! Thanks for sharing. I’ll add it to my open source local n8n stack.

Do you think this type of patching would also work for patching in Langfuse to all LangChain prompt queries?

2 Likes

Here’s a working docker compose version of Stuart’s code. I made some minor modifications to it to fix the “@opentelemetry/api: Attempted duplicate registration of API: context” error I was getting when the image starts up.

It seems to be working great!

2 Likes

Great work. My implementation is definitely rough around the edges and there’s more to be done instrumenting other parts of n8n. There are still a number of operations that result in orphaned spans like credential retrieval requests. It would probably also make sense to adjust some defaults to reduce the number of spans in each execution like cutting out postgres pool connection requests.

Hi,

Thanks for your code. @StuartJohnson

Is it possible to follow traces of the tools used, LLM costs, etc. with your stack? @muxxi
